RGBlink RGB30X-PNDI-TLY - Full HD with HDMI/3G-SDI/LAN/NDI interface, 30X Optical Zoom
Hinnat näkyvät vain verkkokauppaan kirjautuneille käyttäjille.
|
|
RGBlink RGB30X-PNDI-TLY - Full HD with HDMI/3G-SDI/LAN/NDI interface, 30X Optical Zoom
Tuotekoodi:
981-0011-34-0
Full HD with HDMI/3G-SDI/LAN/NDI interface, 30X Optical Zoom
|
RGBlink vue POE&NDI PTZ camera 30X. Full HD with H
|
| Interface | Output | 3G SDI | | 1xBNC | | | | |
| | HDMI | | 1xHDMI-A | | | | |
| | USB | | 1xUSB-A | | | | |
| | LAN | | 1xRJ45 | | | | |
| Audio | IN | | 1x3.5mm Stereo Jack | | |
| Control | RS232 IN/OUT | 2xDIN8 | | | | |
| | RS485 | | 1x4pin Terminal | | | |
| Power | | | 1xDC12V Jack | | | |
| Performance | Camera | | | 12X | 20X | 30X | | |
| | Optical Zoom | | f＝4.1～49.2mm | f＝5.05～91.50mm | f＝5.2～148.4mm | |
| | View Angle | | 6.57°～ 70.28° | 3.45°～ 60.04° | 2.14°～58.1° | |
| | AV | | F1.8 ～ F2.68 | F1.8 ～ F2.9 | F1.3 ～ F4.8 | | |
| | Digital Zoom | 10X | | | | |
| | Minimum Illumination | 0.5Lux (F1.8, AGC ON) | | | |
| | DNR | | 2D & 3D DNR | | | | |
| | White Balance | Auto/Manual/One Push/3000K/3500K/4000K/4500K/5000K/5500K/6000K/6500K/7000K |
| | Focus | | Auto/Manual | | | | |
| | Aperture/Electronic Shutter | Auto/Manual | | | | |
| | BLC | | ON/OFF | | | | |
| | WDR | | OFF/Dynamic Level Adjustment | | | |
| | Video Adjustment | Brightness/Color/Saturation/Contrast/Sharpness/B/W mode/Gamma curve |
| | SNR | | >55dB | | | | |
| | Effective Pixels | 2.07m,16:9 | | | | |
| Pan-and-Tilt Parameter | Pan/Tilt Movement | -170°～+170°/'-30°～+90° | | | |
| Pan/Tilt Control Speed | 0.1～60°/S；0.1～30°/S | | | |
| | Preset Speed/Quantity | Pan:60°/S, Tilt:30°/S; Up to 255 preset positions (10 remote control) |
| | 360° TALLY | full 360° view of TALLY | | | |
| Audio Compression Format | AAC | MP3 | G.711A | | | | | |
| | | | | | | |
| Video Compression Format | H.264 | H.265 | Dual Streaming Output |
| Output Resolutions | 720p50/59.94/60 | 1080p25/29.97/30/50/59.94/60 | 1080i50/59.94/60 | |
| Control Protocol | VISCA | Pelco-D | Pelco-P | | | | |
| Baud Rate(bps) | 115200 | 9600 | 4800 | 2400bps | | | | |
| Network Protocol | RTSP | RTMP | SRT | ONVIF | | | |
| Supported Standards | SDI | SMPTE 425M (Level A & B) | SMPTE 424M | SMPTE 292M | SMPTE 259M-C | DVB-ASI | |
| Power | Input Voltage | DC12V/1.5A | | | | | | |
| Max Power | 12W | | | | | | |
| Environment | Temperature | -10℃～50℃ | | | | | |
| Humidity | 20%～80% | | | | | |
| Physical | Weight | Net | 1.7kg | | | | | |
| Dimension | Net | 180mm(front)×188mm(side)×198mm(height) |
Huomioi, että kuva on suuntaa-antava ja varsinainen tuote saattaa ulkoasultaan poiketa tuotekuvasta (esim. tietokoneisiin ei välttämättä sisälly näyttöä, vaikka kuvassa sellainen olisikin). Jos tuotenimikkeessä on eri tiedot kuin tuotekuvauksessa, tuotenimikkeen tieto on oikein. Jos jokin asia jää epäselväksi, lähetä sähköpostia tukeen ennen tuotteen tilaamista.
