| Camera | | Resolution | 3840*2160,1920*1080,1280*720,960*540,800*600,720*576,720*480,640*480,640*360,352*288,320*240 | | Image Sensor | SONY 1/2.8” Progressive CMOS 8.5 megapixels | | Effective Pixels | 8.5 Megapixels (16:9) | | Video Output | USB 3.0 (Compatible with USB 2.0) | | Lens | 4k Fixed Focus Lens | | Aperture | 2.1mm | | Horizontal View Angle | 110° | | Mechanlcal PTZ | Not support | | Digital Noise Cancellation | 3D Digital Noise Cancellation | | Auto Framing | Support | | Digital Noise Cancellation | 3D Digital Noise Cancellation | | Backlight Compensation | Support | | Image Flip | 180° | | Image Mirror | Support | | White Balance | Automatic / manual | | Intelligent application | Auto framing, digital zoom | | Ant- Flicker | 50HZ/60HZ | | Video Adjustment | Brightness, Gain, Saturability, Contrast ratio, Definition, Gamma | | S/N ratio | >55dB | | Language | English / Chinese | | Remote Control | IR Control | | Audio video | | Pickup | Built in 4 mics | | Speaker | Built in speaker | | Microphone array | Linear array microphone, pickup distance up to 8 meters | | USB Feature | | Protocol | UVC 1.1 | | Operation System | Window7 and above、MacOS、Linux、 Android | | UVC video encoding format | YUY2、MJPEG、H.264、H.265 | | UVC video resolution | 320×240、640×480、720×576、800×600、1280×720、1920×1080,etc | | UVC video FPS | Up to 30fps | | Interface | | USB port | 1 line, USB 3.0, Type-B socket | | MIC | 3.5mm MIC IN | | Audio Expansion | LINE-IN: Support externally extended 3.5mm passive microphone input | | General Specifications | | Input Voltage | DC 12V | | Input Current | Max.1A | | Power Consumption | Max.12W | | Camera Dimensions | (L)400×(W)70×(H)45mm Host (L)400×(W)92×(H)82mm Host with bracket | | Weight | 950g | | Accessories | Power adapter x1, IR remote x1,USB3.0 cable x1, User manual x1 |
Camera |
| Resolution | 3840*2160,1920*1080,1280*720,960*540,800*600,720*576,720*480,640*480,640*360,352*288,320*240 |
| Image Sensor | SONY 1/2.8” Progressive CMOS 8.5 megapixels |
| Effective Pixels | 8.5 Megapixels (16:9) |
| Video Output | USB 3.0 (Compatible with USB 2.0) |
| Lens | 4k Fixed Focus Lens |
| Aperture | 2.1mm |
| Horizontal View Angle | 110° |
| Mechanlcal PTZ | Not support |
| Digital Noise Cancellation | 3D Digital Noise Cancellation |
| Auto Framing | Support |
| Digital Noise Cancellation | 3D Digital Noise Cancellation |
| Backlight Compensation | Support |
| Image Flip | 180° |
| Image Mirror | Support |
| White Balance | Automatic / manual |
| Intelligent application | Auto view, audio tracking, digital zoom |
| Ant- Flicker | 50HZ/60HZ |
| Video Adjustment | Brightness, Gain, Saturability, Contrast ratio, Definition, Gamma |
| S/N ratio | >55dB |
| Language | English / Chinese |
| Remote Control | IR Control |
| Audio video |
| Pickup | Built in 4 mics |
| Speaker | Built in speaker |
| Microphone array | Linear array microphone, pickup distance up to 8 meters |
| USB Feature |
| Protocol | UVC 1.1 |
| Operation System | Window7 and above、MacOS、Linux、 Android |
| UVC video encoding format | YUY2、MJPEG、H.264、H.265 |
| UVC video resolution | 320×240、640×480、720×576、800×600、1280×720、1920×1080,etc |
| UVC video FPS | Up to 30fps |
| Interface |
| USB port | 1 line, USB 3.0, Type-B socket |
| MIC | 3.5mm MIC IN |
| Audio Expansion | LINE-IN: Support externally extended 3.5mm passive microphone input |
| General Specifications |
| Input Voltage | DC 12V |
| Input Current | Max.1A |
| Power Consumption | Max.12W |
| Camera Dimensions | (L)400×(W)70×(H)45mm Host (L)400×(W)92×(H)82mm Host with bracket |
| Weight | 950g |
| Accessories | Power adapter x1, IR remote x1,USB3.0 cable x1, User manual x1 |
