Aurora Multimedia 3rd gen. 4K 10Gbps SDVoE AV-over-IP transceiver box with advanced scaling (ASIC model, dual fiber version)
Hinnat näkyvät vain verkkokauppaan kirjautuneille käyttäjille.
|
|
Aurora Multimedia 3rd gen. 4K 10Gbps SDVoE AV-over-IP transceiver box with advanced scaling (ASIC model, dual fiber version)
Tuotekoodi:
IPX-TC3A-DF-Pro
Multi-Window, videowall, & scaling Zero Compression/Latency 4K streaming over Redundant 10G Networks (Dual Fiber) Seamless Switching up to 128x128 with HDCP Supports Video Wall modes Stereo De-embedded Audio Output SFP+ modules not included (Power Supply PS0081-1 sold separately)
|
Features
- Configure as Transmitter (Encoder) or Receiver (Decoder)
- 4K60 4:4:4 Over 10G Fiber or Copper
- Zero Compression/Frame Latency (22us) for 4K60 4:2:0 and below
- 1.3:1 Lossless Compression and Zero Frame Latency (100us) for 4K60 4:4:4
- Available for 10Gbps fiber MMF/SMF or 10Gbps copper networks
- Network Redundant operation
- Secure Content Encryption
- 128x128 Capable with HDCP, Larger for Non-Encrypted Sources
- Video Wall Capability 8x8 (Pro Version)
- Windowing/Multi-viewer up to 32 windows (Pro Version)
- 3ms Scaling (Pro Version)
- Seamless Switching (Pro Version)
- Break-away Switching
- Audio DSP
- SFP+ for Multi/Single Mode Fiber
- Front Keypad with OLED Display
- Wall Plate Versions also available in white or black
- undefined
Video
| Compression | Zero (4K30 4:4:4/4K60 4:2:0), 1.3:1(4K60 4:4:4) |
| Latency | Zero Frame Latency (100us without Scaling, 3ms with Scaling) |
| Bandwidth | 600MHz |
| HDCP | HDCP 2.2 |
Connectors
| HDMI | 2 Inputs, 1 Output |
| Analog Audio | Stereo Line In/Out (3.5mm TRS Tip is Left, Ring is Right, Sleeve is Ground) |
| 10G Ethernet (CF Version) | (1) 10G Copper RJ-45 330ft CAT 6A PoE+ & (1) 10G Fiber SFP+ (CF version) |
| 10G Ethernet (DF Version) | (2) 10G Fiber SFP+ (DF Version) |
| 1G Ethernet | (1) 10/100/1000M PoE+ (PSE) |
| RS-232 | Up to 115k Baud (3.5mm TRS Tip TX, Ring RX, Sleeve Ground) |
| IR | Bi-Directional (3.5mm TRS Tip TX, Ring 5V, Sleeve Ground) |
| USB | 2 x USB 2.0 Type A, 1 x USB 2.0 Micro |
| Expansion Cards | ExtremeUSB, Dante and ReAX Options |
Control
| Webserver | Built-In Control Server |
| Management Software | IPBaseT Manager (free download) |
| 3rd Party Control | Comprehensive Telnet API including Exclusive Aurora Wrapper Functions |
| |
Physical & Power
| Housing | Black Aluminum Enclosure |
| Dimensions [L x W x H] | 175 x 102 x 27.7mm [6.875" x 4" x 1.09"] |
| Weight | 0.453kg [1.0lbs] |
| Mount | Optional: Rack mount vertical, Rack mount horizontal, Under table mount |
| Power Supply | PoE on 1G or 10G LAN ports |
| Power Consumption | 12.9 Watts |
| Operating Temperature | 0 ~ 40 Celsius [32 ~ 100 Farenheit] |
| Storage Temperature | -20 ~ 60 Celsius [-4 ~ 140 Farenheit] |
| Relative Humidity | 20~90% RH [no condensation] |
